Laser cutting machine NC315 NG
Laser cutting machine NC315 NG
  • Interchangeable shuttle pallets The presence of interchangeable shuttle-type pallets without lifting the lower pallet (cutting is carried out at two levels) allows for quick replacement of workpieces, the re-rolling time is no more than 15 seconds

  • Z-axis acceleration is up to 3g It is important for maintaining a constant distance between the nozzle and the metal sheet at high speeds

  • Automatic tracking system Allows you to maintain optimal focus with an accuracy of 100 microns, which increases and stabilizes the cutting speed and results in getting a high-quality smooth surface of the cut edge

  • Linear motors in three axes It improves the accuracy and speed of cutting parts. We guarantee the performance of our machines and confirm this in practice

  • Cutting head with auto focus Precitec Procutter cutting head guarantee of reliability and quality

  • Due to technical know-how, we use 1 linear motor in X-axis It avoids delays when synchronizing with the second motor

  • Composite Y-beam, which is not subject to deformation due to temperature fluctuations Significantly improves the accuracy of machine tools compared to steel and aluminum beams

  • The X-axis in Navicut machines is located on top, unlike other machines Allows you to avoid sparks on cable routes during cutting

  • The acceleration set parameter is 28ms, one of the best values among all manufacturers Gives an advantage in the cutting speed of complex parts when many braking-acceleration cycles are required

  • Large weight of machines, damping system Vibration reduction and work accuracy increase

  • 4 opening doors on both sides of the machine Facilitates the work of the operator in case of need for access to the working field. Possibility of location of the machine anywhere in the production area

  • CNC from B&R, one of the world leaders in industrial automation These are real-time CNCs that track the position parameters of moving parts up to the 5th derivative. Affects the speed and accuracy of data processing

  • The Navicut machine control software is supplied by the world leader in this field, Metalix Increases the convenience of the operator, and also allows you to use all the features of the machine

  • Cabinet system for all Navicut machines with door position control sensor and viewing windows Ensures safe operation

  • Components of world leaders French linear motors, German compressors, Italian filtration plant. Precitec laser head, IPG laser source, Japanese THK or German INA guides, IGUS flexible cable channels

Laser cutting machine NC315 NG with work area 3000 x 1500 mm.

  • IPG or Raycus laser sources with chiller
  • Precitec or Raytools cutting head
  • Linear motors or pinion rack
  • Filter ventilation unit
  • Powerful compressor optional
  • Production and service in Serbia
  • 3 years warranty

View product
Laser cutting machine NC315
Laser cutting machine NC315
  • Interchangeable shuttle pallets The presence of interchangeable shuttle-type pallets without lifting the lower pallet (cutting is carried out at two levels) allows for quick replacement of workpieces, the re-rolling time is no more than 15 seconds

  • Z-axis acceleration is up to 3g It is important for maintaining a constant distance between the nozzle and the metal sheet at high speeds

  • Automatic tracking system Allows you to maintain optimal focus with an accuracy of 100 microns, which increases and stabilizes the cutting speed and results in getting a high-quality smooth surface of the cut edge

  • Linear motors in three axes It improves the accuracy and speed of cutting parts. We guarantee the performance of our machines and confirm this in practice

  • Cutting head with auto focus Precitec Procutter cutting head guarantee of reliability and quality

  • Due to technical know-how, we use 1 linear motor in X-axis It avoids delays when synchronizing with the second motor

  • Composite Y-beam, which is not subject to deformation due to temperature fluctuations Significantly improves the accuracy of machine tools compared to steel and aluminum beams

  • The X-axis in Navicut machines is located on top, unlike other machines Allows you to avoid sparks on cable routes during cutting

  • The acceleration set parameter is 28ms, one of the best values among all manufacturers Gives an advantage in the cutting speed of complex parts when many braking-acceleration cycles are required

  • Large weight of machines, damping system Vibration reduction and work accuracy increase

  • 4 opening doors on both sides of the machine Facilitates the work of the operator in case of need for access to the working field. Possibility of location of the machine anywhere in the production area

  • CNC from B&R, one of the world leaders in industrial automation These are real-time CNCs that track the position parameters of moving parts up to the 5th derivative. Affects the speed and accuracy of data processing

  • The Navicut machine control software is supplied by the world leader in this field, Metalix Increases the convenience of the operator, and also allows you to use all the features of the machine

  • Cabinet system for all Navicut machines with door position control sensor and viewing windows Ensures safe operation

  • Components of world leaders French linear motors, German compressors, Italian filtration plant. Precitec laser head, IPG laser source, Japanese THK or German INA guides, IGUS flexible cable channels

Laser cutting machine NC315 with work area 3000 x 1500 mm.

  • IPG or Raycus laser sources with chiller
  • Precitec or Raytools cutting head
  • Linear motors or pinion rack
  • Filter ventilation unit
  • Powerful compressor optional
  • Production and service in Serbia
  • 3 years warranty

View product

Competitive advantages

We supply machines to the European Union, USA and Taiwan, where we successfully compete with the above companies

  • Productivity

    Naviсut laser cutting machines provide high-quality metal cutting at high speeds. Fiber lasers up to 30 kW, processing up to 1000 tons of sheet metal per machine monthly.

  • Reliability

    Modern, reliable and expensive components of the best global manufacturers are used for the production of machines.

  • Usability

    Easy to buy, easy to maintain. We are a European manufacturer with 24/7 support.

  • Cost-effectiveness

    The cost of similar machines from leading foreign manufacturers is 30-60% higher. The cost of consumables and maintenance of foreign competitors is higher.

  • Plainness

    The Navicut unit does not require maintaining a “medical cleanliness” of the facility. The laser is resistant to humidity and vibrations in production.

  • Ease of use

    No special training is required to operate and maintain the Navicut unit. The staff is trained to work with the machine within 5 days

Productivity Reliability Usability Cost-effectiveness Plainness Ease of use
Beginning of work

2001

Beginning of work

The Navicut company began its activities in the production of metal laser cutting machines. During the first two years, a team of graduates from top technical universities conducted research and development.

First machine

2003

First machine

The experimental unit for laser cutting of sheet metal with a CO2 laser was made.

Fiber laser technology

2004

Fiber laser technology

A direction is being opened to adapt fiber lasers to machine design. As a result of numerous experiments, it was found that it is significantly superior to the CO2 laser in the most important technological and technical and economic parameters, and is capable of ensuring stable operation of the machine and high-quality metal cutting.

First patent

2005

First patent

As a result of comprehensive tests and improvements of the experimental sample, the first industrial unit appeared with a unique coordinate table on linear drives; the unit is protected by a patent of invention.

Start of series production

2007

Start of series production

Serial production of industrial complexes with fiber lasers has begun. Navicut makes large R&D investments and carries out a lot of experimental work. As a result, dynamic parameters are constantly improved, and the productivity of rolled metal processing increases.

“Doublebeam” machine

2012

“Doublebeam” machine

The first machine with fully independent cutting heads (“doublebeam” machine).

Opening of a new production facility

2014

Opening of a new production facility

Opening production in Estonia

Unique machines in production

2015

Unique machines in production

Development, production, and delivery of a unique solution: a double-beam machine with a processing area of 3050x4050

The model range has reached 25 machines

2016

The model range has reached 25 machines

The Navicut model range includes 25 models of machines with a processing area from 1100x1250 (mm) to 2550x12250 (mm).

First 6 kW machine

2017

First 6 kW machine

The first unit with a 6 kW laser source.

First 12 kW machine

2018

First 12 kW machine

The first unit with a 12 kW laser source.

New technological advances

2019

New technological advances

Two customers have upgraded their machines by installing 15kW laser sources and Precitec Procutter laser heads. This significantly increased cutting speed and productivity when working with metals 4-16 mm thick. The cutting speed of 12 mm steel has increased to 8 m/min.

Opening of another production

2023

Opening of another production

Opening production in Serbia

2001
2003
2004
2005
2007
2012
2014
2015
2016
2017
2018
2019
2023

Design advantages

Patented “wing” system - one synchronous linear electric drive is used for movement on each axis, unlike functional analogues with two or more motors per axis. This eliminates the need for synchronization and, as a result, significantly increases reliability of the equipment

Models with a working area up to 4950x2050 do not require a special foundation

High rigidity and vibration resistance of the machine ensure good quality and accuracy of processing in the entire range of dynamic parameters

Composite Y-beam is much lighter and, at the same time, stronger than metal beam of the functional analogues, which allows to reduce vibrations and increase the dynamics of processing

Cabinet system with sensors for monitoring the position of doors and observation windows made of special glass ensures safe operation of the unit and protects the operator from laser radiation

Availability of replaceable shuttle-type pallets without lifting the lower pallet (cutting is carried out on two levels) allows for quick replacement of workpieces, with the pallet rewinding time not exceeding 15 seconds

Patented collimator allows the use of a standard QBH connector at high accelerations. Vacuum-tight design with a double-loop seal prevents air exchange with the surrounding space and dust ingress into the collimator

Since 2015, Navicut has been equipping its systems with Precitec laser heads (for systems with powerful fiber lasers - 3 kW and more)

Service

Hotline

Navicut service network is expanding

Remote monitoring and diagnostics of
the unit condition

Permanent stock of spare parts

The technician arrives within 1-2 working days
